Multi-purpose sawdust suction machine

Wednesday May-21 2025  17:43:17

The multi-purpose sawdust suction machine is a device that uses the principle of negative pressure airflow to efficiently transport light materials such as sawdust, and has the functions of suction, transportation and unloading. Since sawdust is light, large, easy to fly, and difficult to carry in a centralized manner, the traditional transportation method is inefficient and dusty. The suction machine uses the airflow generated by the fan to suck the sawdust into the pipeline and transports it to the designated location through a hose or a hard pipe. It is suitable for wood processing plants, farms, biomass fuel plants and other places. The equipment has a compact structure and is easy to move. It can meet the transportation needs of various light granular materials such as grain, wood chips, and rice husks. It has strong adaptability and versatility.

The difference between a multi-purpose sawdust suction machine and a sawdust vehicle suction machine

Features	Multi-purpose sawdust suction machine	Sawdust vehicle suction machine
Conveying capacity	5-50 tons per hour	20-50 tons per hour
Conveying distance	According to actual needs	The horizontal conveying distance is generally around 4-12 meters, and the lifting height is usually 3-5 meters
Applicable materials	Sawdust, grain, straw and other materials, suitable for dry and wet raw materials	Sawdust and grain
Mobility	Strong mobility, but usually requires a fixed power supply or supporting equipment	High mobility , suitable for large-scale or cross-regional operations
Function	Integrates crushing, conveying and collecting, and can handle sawdust, grain and crop waste	Mainly used for the suction and loading and unloading of sawdust and grain, emphasizing the function of fast loading and transportation

How does the multi-purpose sawdust suction machine work?

The multi-purpose sawdust suction machine mainly works on the principle of negative pressure pneumatic conveying. Its core components include high-pressure fans, suction pipes, conveying pipes, separation devices and discharge ports. Its working process is as follows:

①Start the fan: After the equipment is turned on, the fan generates a strong negative pressure airflow to form suction at the suction port;

② Inhalation of sawdust: The suction port is placed at the sawdust pile or silo port, and the sawdust is sucked into the pipeline system through the airflow;

③ Pneumatic conveying: Sawdust is transported in the pipeline with high-speed airflow, and can be transported horizontally or vertically to the designated location;

④ Separation and unloading: After entering the main machine, the sawdust and the airflow are separated in the separation device, and the material settles into the discharge port or silo, and the gas is discharged after filtering;

⑤ Closed operation: The whole process is closed, which reduces dust leakage and improves cleanliness and environmental protection.

This equipment is particularly suitable for materials such as sawdust that are light, easy to raise dust, and irregular particles. It has gentle conveying and high efficiency. High and adaptable advantages.

What are the advantages of multi-purpose sawdust suction machine?

High efficiency and energy saving: the processing capacity reaches 1-5 tons/hour, and the energy consumption is 30%-40% lower than that of traditional equipment.

One machine for multiple uses: quickly switch between different materials such as sawdust, grain, and feed through parameter adjustment to reduce repeated investment in equipment.

Safe and low energy consumption: closed transportation reduces material loss (loss rate <1%), and dust emissions meet relevant industry standards.

Flexible adaptation: modular design supports customized transformation and is suitable for a variety of complex environments such as narrow workshops and outdoor venues.

Application of the multi-purpose sawdust suction machine

The multi-purpose sawdust suction machine is widely used in many fields due to its flexibility and versatility, especially in the processing of light and dusty materials.

Wood processing industry: quickly suck out the scattered sawdust generated by woodworking machinery (such as sawing machines and planing machines), keep the workshop clean, and reduce the safety hazards caused by dust accumulation. Connect multiple processing equipment to centrally transport the sawdust generated by each workstation to the storage warehouse or waste treatment area through pipelines to improve the automation of the production process.

Agriculture and horticulture scenarios: mix sawdust with livestock and poultry manure, crop straw, etc. Combined, it is transported to the fermentation tank or mixing equipment through a grain suction machine for making organic fertilizer. In greenhouses or gardening centers, the sawdust is transported to the substrate mixing production line and evenly mixed with soil, fertilizer, etc. to make a plant seedling substrate.

Biomass energy field: In biomass pellet plants and biomass boilers, the sawdust in the storage bin is stably transported to crushers, dryers, pelletizers and other equipment to ensure the continuity of fuel production. The long-distance and high-drop transportation of sawdust in the warehouse (such as from the ground storage bin to the high-level hopper) is realized, which is convenient for storing, sorting or mixing with other raw materials. Materials (such as straw, rice husk).

Price of multi-purpose sawdust suction machine

The market price of multi-purpose sawdust suction machine is affected by many factors, such as brand, model, suction power, functional configuration and market demand, specifications, conveying capacity, material, etc. The price range is roughly between 500 and 30,000 yuan. High-end models may have more automation and high efficiency, so the price will be higher. It is recommended to conduct market research and comparison according to specific needs.

Type	Conveying capacity (tons/hour)	Conveying distance (meters)	Reference price range (RMB)
Small household or simple type	2~4 Tons	10～15 meters	¥500～¥3000
Medium-sized general-purpose	5～8 tons	20～30 meters	¥3000～¥6000
Large-scale industrial	8 tons and above	30 meters and above	¥6000～¥10000 or even higher

In general, multi-purpose sawdust suction machine plays an important role in various occasions where light, granular or powdery materials need to be handled with its easy operation, strong mobility, and efficient suction and transportation. It is an ideal choice for improving production efficiency and working environment.
