Spice Powder Inclined Screw Conveyor Auger
Tuesday February-03 2026 15:06:49
Spice Powder Inclined Screw Conveyor Auger is used for the continuous, inclined conveying of spice powders between different processes and stations, seamlessly connecting crushing, mixing, filling, and drying stages for a more streamlined production flow. The screw pitch is designed to account for the flowability of the spice powder, typically between 100-300mm, but can be adjusted according to powder characteristics. The blades are mostly made of 304 or 316 stainless steel, which is corrosion-resistant and meets food production standards, preventing powder contamination. In applications requiring wear resistance, a Teflon coating is added. The conveying capacity is adjustable from 1-20 m³/h, suitable for small or large batch production. The tilt angle is typically 15°-45°, but can reach 60° for special requirements. The equipment cavity is fully enclosed, with silicone seals at the inlet and outlet, and a dustproof flange in the middle section, reducing powder scattering and dust ingress, keeping the spice powder clean.
Spice Powder Inclined Screw Conveyor Auger Structure
The Spice Powder Inclined Screw Conveyor Auger features a well-organized structural design, consisting of a drive unit, conveying trough, screw shaft, inlet, outlet, and support frame. The drive unit, containing a motor and reducer, provides continuous rotational power to the screw shaft, ensuring smooth and vibration-free conveying. The trough is typically tubular, and its enclosed design makes the equipment more robust and allows the spice powder to move along the channel. The screw shaft inside the trough has welded helical blades that propel the powder forward as it rotates. When conveying at an incline, the blade tips and joints are reinforced to withstand friction from material sliding. The inlet and outlet are designed with flanged interfaces for easy connection to other equipment. The support frame secures the entire conveyor; the inclined mounting base provides greater stability, preventing wobbling during operation and reducing the likelihood of vibration due to a shift in the center of gravity.
Advantages of the Spice Powder Inclined Screw Conveyor Auger
The Spice Powder Inclined Screw Conveyor Auger is suitable for materials such as spice powders that are fine-particle, easily absorb moisture, generate dust, and have volatile aromas. Its fully enclosed conveyor structure prevents dust from flying, protecting the respiratory health of operators and preserving the aroma in the product. The inner wall of the equipment is polished, eliminating dead corners, minimizing material residue, and facilitating easy and rapid cleaning. The conveying process is smooth and gentle, preventing the spice particles from being crushed or damaged, thus maintaining their original aroma and flavor. For powders with high oil content or a tendency to clump, the blade surface is treated, and the screw pitch is adjustable, reducing material adhesion to the blades and trough walls, ensuring smooth conveying. This results in a continuous and smooth production process, improved efficiency, and eliminates the hassle of frequent cleaning.
Spice Powder Inclined Screw Conveyor Auger Parameter Table
| Model | DH-S2-2K | DH-S2-3K | DH-S2-5K | DH-S2-7K | DH-S2-8K | DH-S2-12K |
| Charging Capacity | 2m3/h | 3m3/h | 5 m3/h | 7 m3/h | 8 m3/h | 12 m3/h |
| Diameter of pipe | φ102 | φ114 | φ141 | φ159 | Φ168 | Φ219 |
| Total power | 0.61KW | 0.81W | 1.56KW | 2.26KW | 3.06KW | 4.06KW |
| Total Weight | 100kg | 130kg | 170kg | 200kg | 220kg | 270kg |
| Hopper Volume | 100L | 200L | 200L | 200L | 200L | 200L |
Spice Powder Inclined Screw Conveyor Auger Applications
The Spice Powder Inclined Screw Conveyor Auger is used in all stages of spice processing, including deep processing of natural spices, formulation of compound seasonings, seasoning filling, and conveying powdered auxiliary materials in food processing. Small processing plants can use one machine to connect the crushing and mixing processes, while large enterprises can use multiple machines in conjunction to form an automated conveyor line to meet large-scale production needs. The equipment is flexible in installation, can be floor-mounted or suspended, and the height and angle of the support can be finely adjusted on-site. The inlet and outlet interfaces can be customized to easily connect to crushers, mixers, filling machines, and other equipment. During installation, ensure horizontal and coaxial alignment, grounding of the drive unit, and allowance for operation and maintenance space. During commissioning, run the machine under no-load to confirm there are no abnormal noises or powder leakage before putting it into use. Daily operation and maintenance do not require professional technicians, reducing operating costs.
The Spice Powder Inclined Screw Conveyor Auger, with its rational structural design, optimized technical parameters, and consideration of the characteristics of spice powders, has become a commonly used conveying device in food processing. It solves the problems of dust, contamination, powder leakage, and low efficiency that are common in traditional conveying methods, while also playing a role in preserving spice flavor, ensuring hygiene, and improving the workshop environment. The equipment blades are made of corrosion-resistant stainless steel, and the conveying capacity and screw pitch are adjustable. Combined with a sealing design, it ensures smooth and hygienic material transport. Whether installed at an angle, in confined spaces, or facing strict food hygiene requirements, it operates stably, reducing downtime and cleaning time, and bringing continuity and reliability to the enterprise's production process.
